Description
Hach Company 3415 Portable Air Particle Counter
This item comes with a 30-day Repair or Replace warranty.
-
- Standard Size Channels: 0.5, 1.0, 2.0, 3.0, 5.0, 10.0 µm or 0.5, 1.0, 2.0, 3.0, 5.0, 25.0 µm
- Flow Rate: 28.3 LPM (1.0 CFM) ±5% (default factory setting)
- Light Source: Long Life Laser™ diode with 10-year Mean Time To Failure (MTTF)
- Pump Type: Air vacuum, rated for continuous use
- Count Display: Color 1/4 VGA TFT Touch Screen
- Interface: Windows CE®-based
- Sample/Hold/Delay Times: 1 second to 23 hours 59 minutes 59 seconds
- Count Alarms: 1 to 9,999,999 counts
- Count Cycles: Up to 100 while in automatic mode
- Manifold Supports A3432 32-port Manifold System Location
- Labels: 0 to 999, appears on printout
- Data Storage: 5,000 samples, scrollable on Historical Data review screen
- Communication Interfaces: RS-232, RS-485, 802.11 b/g Wireless, 802.3 Ethernet, USB Client (Version 1.1), USB Host (Version 1.1)
- Communication Protocol Modbus TCP, Modbus RTU, Serial FX
- Battery Type: Lithium-ion smart battery; rechargeable, eject able and hot-swappable
- Operating Time (Battery) 28.3 LPM (1.0 CFM) and 50 LPM (1.77 CFM) up to 6 hours** 100 LPM (3.53 CFM) up to 3 hours**
- Battery Recharge Time: 6.75 hours minimum, 10 hours maximum
- Power 24 VDC 3.2 A with 100-240 VAC 50/60 Hz adapter (included in ship kit)
- Enclosure Material: Stainless Steel
- Operating Temperature: 0 to 40 °C (32 to 104 °F); 10 to 90% relative humidity, non-condensing
- Dimensions (WxDxH): 12.5 x 10 x 8 in.
- Weight (without battery): 16.6 lbs.
