Description
Cytiva BPG 200/500 Chromatography Column – 18110311
This item is in very good condition. Sale is for all shown; glass column, top and bottom flanges, 4 threaded rods, and 2 O-rings. Glass has been inspected for damage.
-
- Autoclavable: 121°C for 30 min, except for the bed support
- Bed Height: 1-26 cm
- Bed Height Packing With Extension Max.: 35 cm
- Bed Height Running With Extension Max.: 45 cm
- Bed Support: Net
- Bed Volume: 0.3-8.1 L
- Bed Volume Packing With Extension Max.: 10.9 L
- Bed Volume Running With Extension Max.: 14.1 L
- Column Cross Section Area: 314 cm²
- Connections: 25 mm TC
- Dimensions: 590 x 590 x 1270 mm
- Footprint: 590 x 590 mm
- Inlet Dimension i.d.: 6 mm
- Material (bed support): Polyamid (PA), Polyetheretherketone (PEEK), Polypropylene (PP)
- Material (column tube): Glass Borosilicate 3.3
- Material (Lid): 316L Stainless Steel (SS)
- Material (Seal): Ethylene propylene diene (EPDM), Fluoroethenepropene (FEP)
- Material (Stand): 316L Stainless Steel (SS)
- Operating pressure max.: 6 bar (87.02 psi)
- Operating Temperature: 4°C-40°C
- Outer Height: 1270 mm
- Porosity: 10 µm, 12 µm, 23 µm and 54 µm
- Surface Finish, Stainless Steel Internal Wetted: Glass Ra < 0.4 μm, SS UNS S32205, SS UNS S31803, SS ASTM 316L Ra 0.5 μm
- Surface Finish Stainless Steel Non-Wetted Parts: Ra Electropolished 3 μm
- Weight: 34 kg
