3M 16EZA Zeta Plus Encapsulated System Holder
This is a used unit is in very good condition. Minor wear. Manufactured 4/2015.
The 3M Zeta Plus 16EZA is a specialized, autoclavable pilot-scale filter holder engineered for biopharmaceutical and biotechnology depth filtration. Designed for single-use encapsulated capsules, it supports scale-up studies and low-volume production filtration, eliminating the need for stainless-steel housings and reducing validation burdens.
- PN: 4552604
- Capacity: Accommodates 1 to 4 of the 0.23 m² capsules, or up to 1 of the 1.6 m² or 2.5 m² capsules
- Configuration Flexibility: The 1-high model supports one to four 0.23 m² capsules, or one full-size capsule.
- Multistage Filtration: Allows both single-stage and two-stage depth filtration to occur simultaneously inside the same holder footprint
- Max Operating Pressure: 3.4 bar (50 psig)
- Max Differential Pressure: 2.4 bar (35 psid)
- Max Operating Temperature: 40°C (104°F)
- Sterilization: Fully autoclavable (1 cycle, 30 minutes at 126°C)
- Height: 25.81 to 47.48 inches, adjustable based on configuration.
- Width: 25.4 in.
- Depth: 16 to 17.8 in.
- Weight: Approximately 22 to 24 lbs.
