Description
Alpha SA-1000 Imager (red) UV Transilluminator White Light Imaging System
This item is in good condition. Powers on, on-board software initializes. Some exterior cosmetic issues, but does not affect function of unit. Manufactured 7/2012.
The Alpha Innotech SA-1000 is a compact, benchtop imaging system designed for UV, white light, and epi-white LED, illumination of gels and blots. It features a 1.3-to-1.4-megapixel camera with 12-bit A/D, motorized/manual zoom lenses, a 3-position filter wheel, and a 302/365 nm UV transilluminator for imaging fluorescent and colorimetric samples.
-
- Camera Resolution: 1.3 or 1.4 Megapixels.
- Imaging Capabilities: UV Transillumination (typically 302/365 nm), Epi-white light illumination.
- Lens: Motorized or Manual Zoom (e.g., 8-48 mm, f/1.2).
- Bit Depth: 12-bit A/D.
- Filter: 3-position wheel (usually with an orange filter).
- Maximum Field-of-View: ~21.8 x 15 cm.
- Dimensions (WxDxH): Approx. 12-14 x 11 x 19-27 in.
- Weight: Approx. 30-63 lbs (13.6-28.8 kg) depending on specific model/cabinet.
- Power: 100-240V, 50/60Hz.
- Applications: DNA/RNA/Protein gel electrophoresis, documentation, and band cutting.
- Software: AlphaView standalone analysis software.
- Design: Compact cabinet with safety interlock for UV protection.
- Front and side USB ports for saving USB drives or connecting to a printer.
