Description
Millipore MP0DSYS2A Process Scale Holder (2 Racks)
This item comes with a 30-Day Limited Warranty
Item is in excellent condition. All operational testing was completed successfully, and unit functions as intended.
- Process Scale Holder with 2 racks
- Valve Type: Gemü® valves
- Pod Capacity: Supports configurations from 5.5 m² to 22 m² of filtration area
- Device Capacity: Holds 5 to 20 pod devices
- Frame Material: 316L stainless steel
- Seal Material: Silicone (SI)
- Gauge Port: 1-1/2 inch sanitary flange
- Inlet/Outlet Ports: 1-1/2 inch sanitary flange
- Hydraulic Cylinder
- Hydraulic Pressure Gauge
- Hydraulic Pump
- Operating Pressure: Typically between 900–1100 psi (62–76 bar); minimum pressure to maintain integrity is 800 psi
- Pods are loaded from the bottom rack up.
- Uses Tri-Clover clamps and alignment rods for secure pod placement.
- Includes manifold brackets for connecting to process piping.
- Designed for easy cleaning (CIP) and maintenance
rbb/rk– 010096 R3.GF
